90mm Galvanized Steel Stick Pins Fixing Pre Formed Insulation Material To Metal Duct

Name: 90mm Galvanized Steel Stick Pins Fixing Pre Formed Insulation Material To Metal Duct
Brand: XIANGYI
Price: 1 USD

China 90mm Galvanized Steel Stick Pins Fixing Pre Formed Insulation Material To Metal Duct wholesale

Brand Name : XIANGYI

Model Number : self stick pins

Certification : ISO9001-2015

Place of Origin : China

MOQ : 10000 pcs

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 380000 sets per 30 days

Delivery Time : 7 work days

Packaging Details : cartons + pallet

Name : Galvanized Steel Stick Pins

Factory : XIangyi Parts

Base Material : Galvanized steel or stainless steel

Base Thickness : 0.4mm plate + 1.0mm double face tape

Pin Material : Galvanized steel or stainless steel or aluminum

Base Size : 40x40, 50x50 etc.

Package Design : Supported

Pin Diameter : 2.7mm or 3mm or 3.4mm etc.

Special Size : Supported

Pin Length : 1" - 12"

Contact Now

90mm Galvanized Steel Stick Pins Fixing Pre-formed Insulation Material To Metal Duct

Quick Details Of The 90mm Insulation Stick Pins

The Self Stick Pins are used to fix the pre-formed insulation to metal duct and can fix fiberglass,

mineral wool, polystyrene, rigid & flexible PU foam, PIR phenolic foam, cork and similar materials.

Name	90mm Galvanized Steel Self Stick Pins
Material	Galvanized
Base Size	50mm x 50mm
Base Thickness	0.4mm
Adhesive Thickness	1.0mm
Pin Diameter	2.7mm
Pin Length	90mm

90mm Galvanized Steel Stick Pins Fixing Pre Formed Insulation Material To Metal Duct

Specifications Of The Self Stick Pins

Material available

Pin material

-mild steel: must be annealed treatment, easy

for bend; zinc coated/copper plated finished

for anti-rust

-aluminum 1100 grade

-annealed stainless steel for specification

Base

Galvanized steel, stainless steel

Common size details

Pin diameter

Pin length

Base thickness

Base size

12ga(2.7mm)

1”-12”

1mm

50x50mm/40x40mm

3mm

1”-12”

1mm

50x50mm/40x40mm

10ga(3.4mm)

1”-12”

1mm

50x50mm/40x40mm

Features Of The Self Stick Pins

* Application specific design

* Corrosion resistance

* Efficiency

* Eco friendly product

* Weather proof

* Long serving life

* Sturdy constructio

Technical Datas Of The Self Stick Insulation Pins

Foam Density: 182 kg/m3
Liner Release Value: 10N/m
Peel Adhesion(23℃): 20 N/25mm
Application Temperature: +10℃ - Advisory
Static Shear: >1000 Hrs(PSTC)
Service Temperature(Minimum): -35℃
Service Temperature(Maximum): +90℃
Tensile Strength: (L)113 N/m2 (CNS10487)(C)85N/m2
Elongation: (L)170% (CNS 10487) (C) 150%
Shelf Life: 2years (20℃ 65%RH)

Application Of The Self Stick Pins

1. Pins are very sharp and easy go through any insulation.
2. Pins are soft and easy to be bent over
3. The tape has a good stickness, every pin could load 1.5kg
4. The tape can work at 5℃ - 80℃

Package Details Of Insulation Stick Pins

PIN LENGTH	CARTON SIZE	QTY/CARTON
38MM	41CMX28CMX17CM	1000PCS
50MM-65MM	41CMX28CMX17CM	500PCS
70MM-84MM	30CMX28CMX29CM	500PCS
90MM-120MM	30CMX30CMX30CM	500PCS
130MM-160MM	30CMX30CMX35CM	500PCS
170MM-203MM	30CMX30CMX28CM	250PCS
OTHERS	SUPPORT CUSTOM

Why choose our HEBEI XIANGYI insulation fasteners?

1.We choose the best quality materials for making insulation fasteners
2.We do copper plating, zinc coated and phosphating pretreatment for the raw material using
drawing machine.
3.We purchase the multi-station cold forging machine to ensure the better mechanical property
of shear connector to match the standard (BS EN ISO13918:2008, AWS D1.1, etc.),
or as per customer's special requirement.
4.We use the automatic riveting machine to install .
5.After rust prevention, XIANGYI insulation fasteners can suitable for long time ship on the sea.
6.Short delivery time because of our reasonable production flow management

Insulation Pins	Insulation Washers
Perforated base insulation hangers	Self locking washers
Self stick insulation pins	Dome cap washers
Lacing anchors and rings	Insulation clips
CD weld pins	Insulation discs
Bi metallic pins
Cup head weld pins
Rock wool metal plugs
Solar Panel Clips
